3/2 Single Solenoid Valve With Spring Return (NC/NO)

Valve

Model No: SSA1BN23CT060V0, STA1BN23CT060V0, SSA2BN23CT120V0, STA2BN23CT120V0

Type: 3X2

Design: Spool with Cartridge Type

Port Size: In/Out – 1/4” BSP & Exhaust – 1/4” BSP

Media: Compressed Air, Filtered & Lubricated

Working Pressure Range: 2 – 10 bar

Ambient/Medium Temperature: 5°- 60° C

Flow: 1200 lpm

Materials of Construction: Aluminium, Nitrile, Brass, Polymer

Coil

Coil Width: 26 mm

Coil Bore: 10 mm

Voltage (V) + 10%: AC (50Hz, 60Hz) – 24V, 110V, 230V DC 12V, 24V

Power Consumption: AC-6W, DC-5W

Duty Cycle: Continuous

Class of Insulation: Class H

Type of Coil Protection: IP65

Features

  • Cartridge Type design for Long life
  • Compact design
  • Manual Override
  • Single and Manifold Mounting
  • Low Power Consumption
  • Fast responce time at maximum 1500 cycle/ min
  • Lubrication not essential
  • Wide range of coil voltages
  • 20 Lacs Cycle tested
